OVERVIEW
CLEAN WATER FROM SALTY WELLS
Well and ground water in many regions contain high levels of dissolved salts, which makes it unsuitable for drinking, irrigation or industrial use. The GAMA series removes these salts with reverse osmosis, producing reliable, high-quality water.
​
Systems are available as skids for plant rooms, or built into containers for remote and outdoor sites.
TYPICAL USES
- Drinking water for towns and villages
​
- Irrigation and greenhouses
​
- Industrial process water
​
- Hotels, resorts and compounds
HOW IT WORKS
INSIDE THE GAMA SYSTEM
Well water is pre-treated and filtered, then pushed through RO membranes at high pressure. Clean water goes to storage, and the concentrate is safely discharged.
STEP 1
Raw water​
Tap, well, river or sea
STEP 1
Well water
Salty ground or well water
STEP 2
Pretreatment
Media filters and antiscalant dosing
STEP 1
Raw water​
Tap, well, river or sea
STEP 3
Cartridge filters
Protect the RO membranes
STEP 1
Raw water​
Tap, well, river or sea
STEP 4
High-pressure RO
Removes dissolved salts
STEP 1
Raw water​
Tap, well, river or sea
STEP 5
Clean Water
Optional remineralization
KEY FEATURES
WHY CHOOSE THE GAMA SERIES
BUILT FOR SALTY WATER
Pumps, vessels and piping designed for brackish salinity.
AUTOMATIC CONTROL
PLC control with alarms, so the system runs by itself.
ANTISCALANT DOSING
Prevents scale from forming on the membranes.
CLEAN-IN-PLACE (CIP)
Built-in cleaning system to extend membrane life.
SKID OR CONTAINER
Choose the format that fits your site.
ENERGY-EFFICIENT PUMPS
Lower power use and lower running costs.
SPECIFICATIONS
TECHNICAL DATA
The full model table, with capacities, dimensions and power for each GAMA model, is in the datasheet.
Capacity range
24–2,500 m³/day
Feed water
Brackish well or ground water
Feed TDS
2,000–10,000 ppm
Format
Skid-mounted or containerized
Pretreatment
[Media filters + cartridge filters]
Control
[PLC with touch screen]
Power supply
[380–415 V, 3-phase, 50 Hz]
